Formlabs VOC Extractor Filtration System for Reducing Volatile Organic Compounds During SLA 3D Printing
Formlabs VOC Extractor Filtration System is a compact external module designed to reduce the concentration of volatile organic compounds (VOC) during the operation of compatible Formlabs photopolymer 3D printers. The device passes air through two carbon filters with an approximate resource of 330 hours of printing. Three fan speeds allow you to adjust the intensity of the airflow according to usage conditions.
Advantages of the Formlabs VOC Extractor System
- Two-stage filtration through two carbon filters. Air sequentially passes through two filter elements that help reduce the concentration of volatile organic compounds during photopolymer 3D printing.
- Approximate resource of 330 hours of printing. The carbon filters are designed for approximately 330 hours of use, allowing you to plan their replacement according to the intensity of equipment operation.
- Three fan speeds. The ability to choose one of three modes allows you to adjust the intensity of the airflow according to the needs of the workflow.
- Quick filter replacement. The system design allows for the replacement of carbon filters in a few seconds, simplifying equipment maintenance.
- Compact design. The VOC Extractor is used as an additional module for a compatible Formlabs 3D printer.
Reducing VOC Concentration During SLA 3D Printing
During the work with photopolymer resins, volatile organic compounds can be released into the air. The Formlabs VOC Extractor is designed to reduce their concentration by passing air through two carbon filters.
The system can be used as an additional means of VOC control in laboratories, offices, educational institutions, and production facilities where compatible photopolymer 3D printers are used.
Compatibility with Formlabs 3D Printers
VOC Extractor is compatible with Formlabs Form Studio 1 and Form 4 photopolymer 3D printers. The system is used as an additional air filtration module to reduce the concentration of volatile organic compounds during printing.
Technical Specifications of Formlabs VOC Extractor
| Parameter | Value |
| Device Type | External air filtration system |
| Filter Type | Carbon |
| Number of Carbon Filters | 2 |
| Filter Resource | 330 hours of printing |
| Number of Fan Speeds | 3 |
| Compatible 3D Printers | Form Studio 1, Form 4 |
| Gross Size | 262 × 167 × 225 mm |
| Gross Weight | 2 kg |
Formlabs VOC Extractor Filtration System is available for order with delivery. Using original replacement carbon filters and timely replacement helps maintain the system's operation during use.
