3D printer CreatBot D600 Pro

CreatBot D600 Pro 3D printer

CreatBot D600 Pro 3D printer thanks to the print volume of 600 x 600 x 600 mm, the heated platform and high temperature of nozzles (420degrees Celsius) you can print large products with the best quality.

Using the CreatBot D600 Pro 3D nozzle with a diameter of 0.4 mm and 3D plastic with a thread diameter of 3 mm You can print objects with a smooth surface at higher speeds.

Perfect for use in industry, education and design.

Features of the CreatBot D600 Pro 3D printer:

  • use of plastic with a diameter of 1.75 mm;
  • presence of 2 nozzles;
  • metal chassis;
  • large print volume 600 x 600 x 600 mm;
  • ultra-high temperature extruder (420 Celsius);
  • translucent camera;
  • ease of cleaning removable panels;
  • Feeder gear motors installed;
  • the presence of a ceramic heating platform (100 Celsius);
  • presence of a metal tray of a heating platform;
  • direct supply of plastic;
  • camera heating;
  • auto platform calibration;
  • plastic drying chamber.

3D CreatBot D600 Pro printer to buy Warsaw

This printer has a huge printing area of ​​600 x 600 x 600 mm and the highest printing speed on the market for 3D printers. This 3D printer is equipped with the CoreXY system, which provides stability and printing accuracy of 0.05 mm, which means high quality 3D printing. The CoreXY system allows you to print at a speed of 120 mm/s.

CreatBot D600 Pro production

The CreatBot D600 Pro 3D printer is equipped with a heated platform made of tempered glass, as well as extruders that can print at a temperature of 350 degrees. These characteristics allow you to diversify the materials used for 3D printing. Perfect for ABS, PLA, PVA, HIPS, wood, nylon, PETG, Rubber, Flexible, Copper, Bronze, Primalloy and others.

The 3D printer has a strong metal case. This allows you to print at high temperatures and at high speeds. The semi-closed camera allows you to monitor the printing process.

CreatBot D600 Pro 3D printer buy Krakow

Due to the fact that the stepper motors are located in the back of the printer, the print head is lighter and provides high speed.

CreatBot D600 Pro 3D printer buy Lublin

In addition to being able to print at high speeds and large objects, the CreatBot D600 Pro 3D printer is also capable of printing objects with a high level of detail and high resolution.

Extruders have interchangeable nozzles available in 0.2 mm, 0.3 mm, 0.4 mm, 0.5 mm, 0.6 mm, 0.8 mm and 1.0 mm for high detail and high speed printing. You can print large prototypes with high strength at high speeds, or small thin objects with high detail. The large CreatBot D600 Pro 3D printer can print with large nozzles up to 1.2 mm in diameter. This allows the layer to be printed thicker and wider for a stronger bond between the layers. As a result, the printing time of the object is significantly reduced.

CreatBot D600 Pro 3D printer buy Poznan

The large 3D printer CreatBot D600 Pro is equipped with an intelligent sensor that detects the presence of thread. If the thread runs out or breaks, the printer pauses and waits for you to insert the thread, and then resumes printing where it was interrupted.

CreatBot D600 Pro 3D printer buy Poland

Modular power management supports automatic shutdown of the printer after printing.

CreatBot D600 Pro 3D printer buy Warsaw

The multifunction display shows information about the status of the 3D printer and allows you to make adjustments to the printer. You can easily change the print temperature, print speed, flow rate and fan speed, pause, pause or resume printing.

Controls allow you to make adjustments while you type.

Specifications

Type of 3D printingFDM
Print area600 x 600 x 600 mm
Number of extruders2
Layer height50 microns
Printing accuracy50 microns
Plastic diameter3 mm (1.75 mm optional)
Compatible plastics
PLA, PLA +, ABS, ABS +, ASA, Elastane, Plastan, Primalloy, Carbon Fiber, Nylon (PA), PC, PETG, HIPS, PP, CoPET, PET, POM, Flexible, TPU, PVA, PEEK, ceramic, conductive, refractory, bronze, copper, aluminum, brass, wood plastic, etc.
Nozzle diameter0.4 mm (available 0.2, 0.3, 0.5, 0.6, 0.8, 1.0 mm)
File type for 3D printingGCO, GCODE
Ambient temperature15-32 °C
Maximum nozzle temperature420 °C
Maximum platform temperature100 °C
Maximum camera temperature70 °C
The drying temperature of the thread65 °C
Better print speed45 mm/s
Maximum print speed120 mm/s
Maximum speed of movement200 mm/s
ConstructionPowder steel, aluminum for motion components, POM
Heating platformMicrocrystalline ceramic panel
Platform calibrationAutomatically
Stepper motorsStep angle 1.8°, microstep 1/16
XY positioning accuracy5.08 microns
Positioning accuracy Z1.25 microns
Power supply100 - 240 V, 50 - 60 Hz
Maximum power4000 W
LCD display4.3″ Touch screen with multilingual interface
ProcessorATmega 2560
Data carrierSD Card
ConnectionUSB
SoftwareCreatWare in multi-language
Supported file typesSTL, OBJ, AMF
Operating SystemWindows (7,8,10), Mac OS X.
Housing materialMetal
Dimensions915 x 845 x 1085 mm
Weight125 kg
Dimensions in the package1000 x 1030 x 1360 mm
Weight in the package190 kg
Producing countryChina

Main page

FDM printer options
Printing technology FDM
Minimum layer height (micron) 50
Build Field (mm) 600*600*600
Ø of plastic (mm) 3 (1.75 optional)
Print temperature (°C) Above 270
Number of extruders 2
Chamber type Closed
Heating the chamber Yes
Plastic drying Yes
Autocalibration Yes
Feeder type Direct
Other options
Diameter of the nozzle (mm) 0,4 (optional 0,2; 0,3; 0,5; 0,6; 0,8; 1,0)
Positioning accuracy (µm) ХY: 5,08; Z: 1,25
Printing accuracy (µm) 50
Print speed (mm/s) From 45 to 120
Maximum carriage speed (mm/s) 200
Maximum nozzle temperature (°C) 420
Maximum chamber temperature (°C) 70
Heating the platform Yes
Maximum platform temperature (°C) 100
Platform material Borosilicate glass bed
Drying thread temperature (°C) 65
Special Function Save data when power is off; Pause printing when filament run out; Turn off the power automatically when printing is complete
Printing material PLA, ABS, PLA+, ABS+, ASA, HPLA, Elastan, Plastan, Primalloy, Flex, TPU, TPE, PMMA, PET, POM, PEEK, PA (Nylon), PA6, Conductive ABS, Flame Retardant, Marble White PLA, Ceramic, Aluminium, Copper, Bronze, Brass and Gold PLA filaments, Wood, Carbon Fiber, PC, PETG, HIPS, PP, PVA
Operating system Windows (7,8,10), Mac OS X
Software CreatWare
CPU ATmega 2560
Printer control 4.3″ Multilingual Touch Screen
Connectivity SD, USB
File format STL, OBJ, AMF, GCO, GCODE
Power supply 100~240V, 50~60Hz, 4000W
Assembly type Supplied assembled
Body material Powder steel, aluminum for motion components
Manufacturer country China
Warranty period (months) 12
