3D printer Formlabs Form 3L

Formlabs Form 3L 3D Printer

Form 3L 3D printer Formlabs Form 3L 3D printer has five times the build volume and twice the laser power of the Formlabs Form 3.

Build Volume: 335 × 200 × 300 mm

Layer height: 25 microns

Buy Formlabs Form 3L 3D printer

  • The next generation of industrial 3D printing

With advanced Low Level Stereolithography (LFS) ™ technology, Formlabs has completely redesigned  photopolymer 3D printing to dramatically reduce the effort of the printing process.

  • Low Force Stereolithography (LFS)™

Uses flexible reservoir and linear backlighting to provide stunning print quality and printer reliability.

  • Twice as powerful laser

Two spaced apart light processing units (LPUs) inside the printer use a compact lens and mirror system for accurate, reproducible prints.

  • Fast printing

Two LPUs work simultaneously on an optimized print path to efficiently see through parts of all sizes.

  • Crisp, clean features

Each high density laser passes through a spatial filter to ensure a clean laser spot.

  • Constant accuracy

The parabolic mirror ensures that the laser prints perpendicular to the build plane, ensuring uniform print quality across the entire platform.

Features Form 3L

  • Continuous printing

Built-in sensors help you maintain ideal printing conditions and send you alerts on the health of your machine.

  • High material capacity:

The Form 3L can contain two easily switchable resin-coated cartridges, preventing interruptions when printing large print works.

  • Closed Loop Calibration

Optical sensors constantly adjust scale and power and can even detect dust.

  • User-replaceable components

Light processing units, resin reservoir, rollers and optics window are field replaceable, reducing the need to replace the printer.

Basic Wholesale Package includes:

Select 1, 2 or 3 years Service Plan in Available Options above.


SLA printer options
Printing technology LFS
Build Field (mm) 335 × 200 × 300
Minimum layer height (micron) 25
Other options
Printing accuracy (µm) 25
Laser characteristics Two lasers 250 mW power Wavelength 405 nm Laser spot 85 μm Certification EN 60825-1:2007
Resin Cartridges 2
Resin filling system Automatic
Supports Autogenerated, Light-Touch Removal
Supported Materials Photopolymer resin
Operating system Windows 7 (64-bit) or Mac OS X 10.12 and higher; OpenGL 2.1; 4 GB RAM (8 GB recommended)
Printer control 5.5″ Colored touchscreen
Supported file types .STL, .OBJ, .FORM
Software Formlabs PreForm
Connectivity Wifi, Ethernet, USB 2.0
Power supply 100~240 V, 650 W, 8.5 A, 50-60 Hz
Manufacturer country USA
Warranty period (months) 12
Package contains 3D printer, Form 3L Resin Tank V2, Form 3L Build Platform, Form 3L Finish Kit: Cleaning Tools, Form 3L Finish Kit: Rinse Bucket V2, PreForm Software, Formlabs Pro Service Plan (1, 2 or 3 Years)
Device parameters
Weight Netto (kg) 54,4
Minimum Access Dimensions (mm) 900 × 960 × 1040
Dimensions Assembled (mm) 770 × 520 × 740
Weight Brutto (kg) 61,0

Basic Wholesale Package includes:

  • Form 3L 3D printer
  • Form 3L Resin Tank V2
  • Form 3L Build Platform
  • Form 3L Finish Kit: Cleaning Tools
  • Form 3L Finish Kit: Rinse Bucket V2
  • Formlabs PreForm Software
  • Formlabs Pro Service Plan for 1, 2 or 3 years



Complete Wholesale Package includes:

  • Form 3L 3D printer
  • Form 3L Resin Tank V2
  • Form 3L Build Platform
  • Form 3L Finish Kit: Cleaning Tools
  • Form Wash L
  • Form Cure L 230V
  • Formlabs PreForm Software
  • Formlabs Pro Service Plan for 1, 2 or 3 years
